ANSI PLUS Plan 7352

The ANSI PLUS MP52 series aligns with ANSI Plans 7352 and 7353. The 7352 is designed to support liquid buffer fluid for a containment seal chamber that is below the seal chamber pressure. The 7353 is a pressurized system designed to isolate the seal from the process completely by providing liquid barrier fluid at a pressure higher than the seal chamber.

The ANSI PLUS 52/53 is designed to support industrial tandem / dual seal applications with medium pressures and temperatures.

• 3 Gallon Capacity at Normal Liquid Level
• 304 Stainless Steel Construction
• 8″ Body with Hemispherical Bottom / Top
• Armored Weld Pad Level Gauge
• 350 PSIG MAWP (-20F to 200F)
• Liquid Filled Pressure Gauge with Block/Bleed Valve
• Orifice Union (Plan 52)
• Ball Valves on Vent and Drain
• Cooling Coils, Pressure / Level Switches Optional
